Модуль супервизора Cisco VS-S2T-10G= в Воронеже

Vendor Code	VS-S2T-10G=

General
Device Type	Control processor
Approximate Width	14.4 in
Approximate Depth	16 in
Approximate Height	1.7 in
Approximate Weight	11.9 lbs
Processor / Memory / Storage
RAM	2 GB ( 4 GB max )
Flash Memory	1 GB
Networking
Form Factor	Plug-in module
Connectivity Technology	Wired
Data Link Protocol	10 Gigabit Ethernet
Performance	IPv4 routing : 720 MppsIPv6 routing : 390 Mpps
Capacity	MAC addresses : 128000IPv4 routes : 256000IPv6 routes : 128000NetFlow entries : 512000Virtual interfaces (VLANs) : 4000Multicast entries (IPv4) : 128000Multicast entries (IPv6) : 128000
Features	Layer 3 switching, layer 2 switching, NAT support, VPN support, MPLS support, IGMP snooping, IPv6 support, Access Control List (ACL) support, Quality of Service (QoS), MPLS VPN, IPv4 support, NetFlow
Compliant Standards	IEEE 802.1x
Communications
Supported Flash Memory Cards	CompactFlash Card
Expansion / Connectivity
Expansion Slots	3 (total) / 3 (free) x SFP (mini-GBIC)2 (total) / 2 (free) x X2
Interfaces	1 x 1000Base-T (management) - RJ-451 x management - RJ-451 x USB - Type A1 x USB - Type B
Compatible Slots	1 x expansion slot
Miscellaneous
Compliant Standards	FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, EN300-386
Power
Power Consumption Operational	435 Watt
Manufacturer Warranty
Service & Support	90 days warranty
Service & Support Details	Limited warranty - 90 days
Environmental Parameters
Min Operating Temperature	32 °F
Max Operating Temperature	104 °F
Humidity Range Operating	10 - 90% (non-condensing)
Compatibility Information
Designed For	Cisco Catalyst 6503-E, 6503-E chassis with Supervisor Engine 32, 6503-E Firewall Security System Bundle, 6503-E WSLM Bundle, 6504-E, 6504-E Application Control Engine (ACE) 20 Bundle, 6504-E chassis with Supervisor Engine 32, 6504-E with Supervisor Engine 720-3B, 6504-E with WiSM Bundle, 6506-E, 6506-E chassis with Supervisor Engine 32, 6506-E Firewall Security System Bundle, 6506-E IDSM-2 Bundle with 2-Gbps Performance, 6506-E IPSec VPN SPA Security System Bundle, 6506-E VPN System, 6506-E WLSM Bundle, 6509-E, 6509-E 10Gig Firewall Security System Bundle, 6509-E Application Control Engine (ACE) 20 Bundle, 6509-E Application Control Engine (ACE) 30 8G Bundle, 6509-E chassis with Supervisor Engine 32, 6509-E Data Center Services Bundle, 6509-E Firewall Security System Bundle, 6509-E Firewall Security System Bundle with Supervisor Engine 720-3BXL, 6509-E IPSec VPN SPA Security System, 6509-E with Supervisor Engine 720, 6509-E with WiSM Bundle, 6509-V-E, 6513-E
